8.6.4. Moltemplate Tutorial

In this tutorial, we are going to use the tool Moltemplate to set up a classical molecular dynamic simulation using the OPLS-AA force field. The first task is to describe an organic compound and create a complete input deck for LAMMPS. The second task is to map the OPLS-AA force field to a molecular sample created with an external tool, e.g. PACKMOL, and exported as a PDB file. The files used in this tutorial can be found in the tools/moltemplate/tutorial-files folder of the LAMMPS source code distribution.

Simulating an organic solvent

This example aims to create a cubic box of the organic solvent formamide.

The first step is to create a molecular topology in the LAMMPS-template (LT) file format representing a single molecule, which will be stored in a Moltemplate object called _FAM inherits OPLSAA {}. This command states that the object _FAM is based on an existing object called OPLSAA, which contains OPLS-AA parameters, atom type definitions, partial charges, masses and bond-angle rules for many organic and biological compounds.

The atomic structure is the starting point to populate the command write('Data Atoms') {}, which will write the Atoms section in the LAMMPS data file. The OPLS-AA force field uses the atom_style full, therefore, this column format is used: # atomID molID atomType charge coordX coordY coordZ. The atomIDs are replaced with Moltemplate $-type variables, which are then substituted with unique numerical IDs. The same logic is applied to the molID, except that the same variable is used for the whole molecule. The atom types are assigned using @-type variables. The assignment of atom types (e.g. @atom:177, @atom:178) is done using the OPLS-AA atom types defined in the “In Charges” section of the file oplsaa.lt, looking for a reasonable match with the description of the atom. The resulting file (formamide.lt) follows:

_FAM inherits OPLSAA {

  # atomID    molID  atomType  charge  coordX  coordY  coordZ
  write('Data Atoms') {
    $atom:C00 $mol   @atom:177  0.00    0.100   0.490   0.0
    $atom:O01 $mol   @atom:178  0.00    1.091  -0.250   0.0
    $atom:N02 $mol   @atom:179  0.00   -1.121  -0.181   0.0
    $atom:H03 $mol   @atom:182  0.00   -2.013   0.272   0.0
    $atom:H04 $mol   @atom:182  0.00   -1.056  -1.190   0.0
    $atom:H05 $mol   @atom:221  0.00    0.144   1.570   0.0
  }

  # A list of the bonds in the molecule:
  # BondID   AtomID1   AtomID2
  write('Data Bond List') {
    $bond:C1 $atom:C00 $atom:O01
    $bond:C2 $atom:C00 $atom:H05
    $bond:C3 $atom:C00 $atom:N02
    $bond:C4 $atom:N02 $atom:H03
    $bond:C5 $atom:N02 $atom:H04
  }
}

You don’t have to specify the charge in this example because they will be assigned according to the atom type. Analogously, only a “Data Bond List” section is needed as the atom type will determine the bond type. The other bonded interactions (e.g. angles, dihedrals, and impropers) will be automatically generated by Moltemplate.

If the simulation is non-neutral, or Moltemplate complains that you have missing bond, angle, or dihedral types, this means at least one of your atom types is incorrect.

The second step is to create a master file with instructions to build a starting structure and the LAMMPS commands to run an NPT simulation. The master file (solv_01.lt) follows:

# Import the force field.
import /usr/local/moltemplate/moltemplate/force_fields/oplsaa.lt
import formamide.lt # after oplsaa.lt, as it depends on it.

# Create the input sample.
solv = new _FAM [5].move( 4.6, 0, 0)
                [5].move( 0, 4.6, 0)
                [5].move( 0, 0, 4.6)
solv[*][*][*].move(-11.5, -11.5, -11.5)

# Set the simulation box.
write_once("Data Boundary") {
 -11.5 11.5 xlo xhi
 -11.5 11.5 ylo yhi
 -11.5 11.5 zlo zhi
}

# Create an input deck for LAMMPS.
write_once("In Init"){
 # Input variables.
 variable run    string solv_01   # output name
 variable ts     equal  1         # timestep
 variable temp   equal  300       # equilibrium temperature
 variable p      equal  1.        # equilibrium pressure
 variable d      equal  1000      # output frequency
 variable equi   equal  5000      # Equilibration steps
 variable prod   equal  30000     # Production steps

 # PBC (set them before the creation of the box).
 boundary p p p
}

# Run an NPT simulation.
write_once("In Run"){
 # Derived variables.
 variable tcouple equal \$\{ts\}*100
 variable pcouple equal \$\{ts\}*1000

 # Output.
 thermo          \$d
 thermo_style custom step etotal evdwl ecoul elong ebond eangle &
 edihed eimp ke pe temp press vol density cpu
 thermo_modify flush yes

 # Trajectory.
 dump TRJ all dcd \$d \$\{run\}.dcd
 dump_modify TRJ unwrap yes

 # Thermalisation and relaxation, NPT ensemble.
 timestep       \$\{ts\}
 fix             NPT all npt temp \$\{temp\} \$\{temp\} \$\{tcouple\} iso \$p \$p \$\{pcouple\}
 velocity all create \$\{temp\} 858096 dist gaussian
 # Short runs to update the PPPM settings as the box shinks.
 run    \$\{equi\} post no
 run    \$\{equi\} post no
 run    \$\{equi\} post no
 run    \$\{equi\}
 # From now on, the density shouldn't change too much.
 run    \$\{prod\}
 unfix NPT
}

The first two commands insert the content of files oplsaa.lt and formamide.lt into the master file. At this point, we can use the command solv = new _FAM [N] to create N copies of a molecule of type _FAM. In this case, we create an array of 5*5*5 molecules on a cubic grid using the coordinate transformation command .move( 4.6, 0, 0). See the Moltemplate documentation to learn more about the syntax. As the sample was created from scratch, we also specify the simulation box size in the “Data Boundary” section.

The LAMMPS setting for the force field are specified in the file oplsaa.lt and are written automatically in the input deck. We also specify the boundary conditions and a set of variables in the “In Init” section. The remaining commands to run an NPT simulation are written in the “In Run” section. Note that in this script, LAMMPS variables are protected with the escape character \ to distinguish them from Moltemplate variables, e.g. \$\{run\} is a LAMMPS variable that is written in the input deck as ${run}.

Compile the master file with:

moltemplate.sh -overlay-all solv_01.lt

And execute the simulation with the following:

mpirun -np 4 lmp -in solv_01.in -l solv_01.log
_images/solv_01.png

Snapshot of the sample at the beginning and end of the simulation. Rendered with Ovito.

Mapping an existing structure

Another helpful way to use Moltemplate is mapping an existing molecular sample to a force field. This is useful when a complex sample is assembled from different simulations or created with specialized software (e.g. PACKMOL). As in the previous example, all molecular species in the sample must be defined using single-molecule Moltemplate objects. For this example, we use a short polymer in a box containing water molecules and ions in the PDB file model.pdb.

It is essential to understand that the order of atoms in the PDB file and in the Moltemplate master script must match, as we are using the coordinates from the PDB file in the order they appear. The order of atoms and molecules in the PDB file provided is as follows:

  • 500 water molecules, with atoms ordered in this sequence:

    ATOM      1  O   MOL D   1       5.901   7.384   1.103  0.00  0.00      DUM
ATOM      2  H   MOL D   1       6.047   8.238   0.581  0.00  0.00      DUM
ATOM      3  H   MOL D   1       6.188   7.533   2.057  0.00  0.00      DUM

  • 1 polymer molecule.

  • 1 Ca2+ ion.

  • 2 Cl- ions.

In the master LT file, this sequence of molecules is matched with the following commands:

# Create the sample.
wat=new SPC[500]
pol=new PolyNIPAM[1]
cat=new Ca[1]
ani=new Cl[2]

Note that the first command would create 500 water molecules in the same position in space, and the other commands will use the coordinates specified in the corresponding molecular topology block. However, the coordinates will be overwritten by rendering an external atomic structure file. Note that if the same molecule species are scattered in the input structure, it is recommended to reorder and group together for molecule types to facilitate the creation of the input sample.

The molecular topology for the polymer is created as in the previous example, with the atom types assigned as in the following schema:

_images/PolyNIPAM.jpg

Atom types assigned to the polymer’s repeating unit.

The molecular topology of the water and ions is stated directly into the master file for the sake of space, but they could also be written in a separate file(s) and imported before the sample is created.

The resulting master LT file defining short annealing at a fixed volume (NVT) follows:

# Use the OPLS-AA force field for all species.
import /usr/local/moltemplate/moltemplate/force_fields/oplsaa.lt
import PolyNIPAM.lt

# Define the SPC water and ions as in the OPLS-AA
Ca inherits OPLSAA {
  write("Data Atoms"){
    $atom:a1  $mol:. @atom:354 0.0  0.00000 0.00000 0.000000
  }
}
Cl inherits OPLSAA {
  write("Data Atoms"){
    $atom:a1  $mol:. @atom:344 0.0  0.00000 0.00000 0.000000
  }
}
SPC inherits OPLSAA {
  write("Data Atoms"){
    $atom:O  $mol:. @atom:76 0.  0.0000000 0.00000 0.000000
    $atom:H1 $mol:. @atom:77 0.  0.8164904 0.00000 0.5773590
    $atom:H2 $mol:. @atom:77 0. -0.8164904 0.00000 0.5773590
  }
  write("Data Bond List") {
    $bond:OH1 $atom:O $atom:H1
    $bond:OH2 $atom:O $atom:H2
  }
}

# Create the sample.
wat=new SPC[500]
pol=new PolyNIPAM[1]
cat=new Ca[1]
ani=new Cl[2]

# Periodic boundary conditions:
write_once("Data Boundary"){
  0 26 xlo xhi
  0 26 ylo yhi
  0 26 zlo zhi
}

# Define the input variables.
write_once("In Init"){
  # Input variables.
  variable run    string sample01  # output name
  variable ts     equal  2         # timestep
  variable temp   equal  298.15    # equilibrium temperature
  variable p      equal  1.        # equilibrium pressure
  variable equi   equal  30000     # equilibration steps

  # PBC (set them before the creation of the box).
  boundary p p p
  neighbor        3 bin
}

# Run an NVT simulation.
write_once("In Run"){
  # Set the output.
  thermo          1000
  thermo_style    custom step etotal evdwl ecoul elong ebond eangle &
  edihed eimp pe ke temp press atoms vol density cpu
  thermo_modify flush yes
  compute pe1 all pe/atom pair
  dump TRJ all custom 100 \$\{run\}.dump id xu yu zu c_pe1

  # Minimise the input structure, just in case.
  minimize        .01 .001 1000 100000
  write_data \$\{run\}.min

  # Set the constrains.
  group watergroup type @atom:76 @atom:77
  fix 0 watergroup shake 0.0001 10 0 b @bond:042_043 a @angle:043_042_043

  # Short annealing.
  timestep        \$\{ts\}
  fix       1 all nvt temp \$\{temp\} \$\{temp\} \$(100*dt)
  velocity    all create \$\{temp\} 315443
  run             \$\{equi\}
  unfix 1
}

In this example, the water model is SPC and it is defined in the oplsaa.lt file with atom types @atom:76 and @atom:77. For water we also use the group and fix shake commands with Moltemplate @-type variables, to ensure consistency with the numerical values assigned during compilation. To identify the bond and angle types, look for the extended @atom IDs, which in this case are:

replace{ @atom:76 @atom:76_b042_a042_d042_i042 }
replace{ @atom:77 @atom:77_b043_a043_d043_i043 }

From which we can identify the following “Data Bonds By Type”: @bond:042_043 @atom:*_b042*_a*_d*_i* @atom:*_b043*_a*_d*_i* and “Data Angles By Type”: @angle:043_042_043 @atom:*_b*_a043*_d*_i* @atom:*_b*_a042*_d*_i* @atom:*_b*_a043*_d*_i*

Compile the master file with:

moltemplate.sh -overlay-all -pdb model.pdb sample01.lt

And execute the simulation with the following:

mpirun -np 4 lmp -in sample01.in -l sample01.log
_images/sample01.png

Sample visualized with Ovito loading the trajectory into the DATA file written after minimization.

(OPLS-AA) Jorgensen, Maxwell, Tirado-Rives, J Am Chem Soc, 118(45), 11225-11236 (1996).
